Brand: HPE | Product Line: HPE ProLiant | Model: DL320 Gen12 | Manufacturer: HPE Smart Buy Express | Clock Speed: 2.3 GHZ | Cores: 16-core | Max Turbo Speed: 3.8 GHZ | Processor Brand: Intel | Processor Generation: 6 | Processor Main Features: 150W TDP, 32 Threads | Processor Number: 6515P | Processor Type: Xeon | Processors Installed: 1 | Server Scalability: 1-way | Total Processor Supported: 1 | Available Memory Slots: 31 | Cache Memory Installed: 72 megabyte | Configuration Features: 1 x 64 GB | Features: Dual rank | Max Memory Supported: 8 TB | Memory Slots: 32 | Memory Technology: DDR5 SDRAM | RAM Installed: 64 GB | Drive Type: No optical drive | Optical Drive Type: No optical drive, None | Optical Drive Type (2nd): None | Storage (2nd): None | Storage (3rd): None | Storage (4th): None | Storage Controller (2nd): None | Storage Controller Name: Intel VROC NVMe Software RAID | Type: None | Hard Drive Interface Type: No HDD | Remote Management: IPMI 2.0, SNMP 3 | Remote Management Controller: Integrated Lights-Out 7 | Expansion Bays: 8 (total) / 8 (free) x hot-swap 2.5″ SFF | Slots: 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode), 2 (total) / 2 (free) x PCIe 5.0 x16 – half-length, full-height (x16 mode) | Interface Provided: 1 x HPE iLO (1 in front) (service port), 1 x USB 2.0 (1 front), 1 x VGA, 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal) | Display Technology: None. | Video Interfaces: VGA | Installed Size: 16 megabyte | Power Device Type: Power supply – hot-plug | Power Provided: 1000 watt | Power Supplies Installed: 2 | Power Supplies Supported: 2 | Redundant Power Supply: Optional | Redundant Power Supply Supported: 1+1 (with optional power supply) | Required Voltage: AC 100-240 volt | 80 PLUS Certification: 80 PLUS Titanium | Operating System Edition: No operating system | Embedded Security: Trusted Platform Module (TPM 2.0) Security Chip | Form Factor: Rack-mountable | Form Factor (RAM): DIMM 288-pin | Max Operating Temperature: 95 degree Fahrenheit | Min Operating Temperature: 50 degree Fahrenheit | Operating Humidity: 8 – 90% RH (non-condensing) | Country: North America | Printer Product Type: None | Hot-Swap Bays: 8 | Manufacturer Form Factor: Rack-mountable | Packaged Quantity: 1 | Product Type: Server | Server Storage Bays: Hot-swap | Server Swappable Drive Form Factor: 2.5″ | Server Swappable Drive Form Factor (metric): 6.4 cm | Server Swappable Drive Interface: SATA/SAS/PCI Express | Height: 1.7 inch | Height (Rack Units): 1 | Width: 17.1 inch | Depth: 23.9 inch | Color Category: Black, Silver | Compliant Standards: ACPI 6.3, AES, ASHRAE Class A3, ASHRAE Class A4, FIPS 140-3, IPv6 Ready, PCI DSS, TLS v1.2, Triple DES, WEEE 2002/95/EC | ENERGY STAR Certified: Yes | EPEAT Compliant: No | TCO Certified: No | On-Site Warranty: On-site | Service & Support Details: Limited warranty – parts and labor – 3 years – on-site – response time: next business day | Limited Warranty: 3 Year
